efficiently monitor existing storage resources, but it also aids in the planning and implementation of
future policy changes. FSRM tasks include:
• Quota Management
• File Screening Management
• Storage Report Management
• Classification Management
Multipath I/O (MPIO)
Microsoft Multipath I/O (MPIO) is a framework provided by Microsoft, which enables storage providers to
develop multipath solutions that contain the hardware-specific information. It is required to optimize
connectivity with their storage arrays. These modules are called Device-Specific Modules (DSMs). MPIO
is protocol-independent and can be used with Fibre Channel, Internet SCSI (iSCSI), and Serial Attached
SCSI (SAS) interfaces in Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, and
Windows Server 2012 R2.
MPIO provides the following features:
• High application availability through failover clustering
• High availability for storage arrays
• SAS disk compatibility
• The ability to perform MPIO tasks through Windows PowerShell cmdlets
NOTE: To work with the DSM provided by Microsoft, storage must be SCSI Primary Commands-3
(SPC-3) compliant.
Managing Devices On MPIO
To manage devices on MPIO:
1. In the Server Manager menu bar, click Tools → MPIO .
The MPIO Properties window is displayed.
2. On the MPIO Devices tab, click Add and enter the Device hardware ID of the device you want to add
MPIO support for and click OK.
3. The device hardware ID's are seen in the Discover Multi-Paths tab.
NOTE: A device hardware ID is a combination of vendor’s name and a product string that
matches the device ID that is maintained by MPIO in its supported device list. The vendor and
product IDs are provided by the storage provider, and they are specific to each type of
hardware.
4. On the DSM Install tab, enter the DSM INF file and click Install or Uninstall to install/Uninstall a DSM.
5. On the Configuration Snapshot tab, capture the snapshot of the current MPIO configuration on the
system, specify a filename for the information to be captured and click Capture.
