Dell Latitude D600 User Manual
Page 43
2.
Close the display and turn the computer over.
3.
Use a #1 Phillips screwdriver to remove the M2 x 3-mm screw from the bottom of the computer.
4.
Press the device latch release so that the latch release pops out.
5.
Pull the device by the latch release to remove the device from the module bay.
Back to Contents Page
NOTICE:
To prevent damage to devices, place them in a safe, dry place when they are not installed in the computer. Avoid pressing down on them or
placing heavy objects on top of them.
1
M2 x 3-mm screw
7P786
