6. Turn the computer over and remove the nine M2.5 x 8-mm screws.
7. Starting at the back center of the palm rest, use your fingers to separate the palm rest from the computer base by lifting the inside of the palm rest
while pushing in on the outside.
Back to Contents Page
1 back center of the palm
rest
2 touch pad connector
3 system board connector
4 computer base
1 M2.5 x 8-mm screws (9) 3R690
NOTICE: Carefully separate the palm rest from the computer base to avoid damage to the palm rest.
