Dell Latitude D600 - Manual (Page 21)

4. Remove the keyboard:
a. Remove the two M2.5 x 6-mm screws across the top of the keyboard.
a. Rotate the keyboard up and slide it forward.
b. Hold the keyboard up and slightly forward to allow access to the keyboard connector.
c. Pull up on the keyboard connector tab to disconnect the keyboard connector from the system board.
Back to Contents Page
1 center control cover 8M659
NOTICE: The keycaps on the keyboard are fragile, easily dislodged, and time-consuming to replace. Be careful when removing and handling the
keyboard.
5. To replace the keyboard, perform the steps used to remove the keyboard in reverse order.
NOTE: When you replace the keyboard, ensure that the keyboard tabs are completely in place to avoid scratching the palmrest.
1 M2.5 x 6-mm screws (2) 057HW
2 keyboard tabs
3 palm rest
