9. Press in both sides of the top display cable connector, and pull the display cable connector away from the top flex-cable connector.
Display Latch
1. Remove the keyboard .
2. Remove the display assembly .
3. Remove the display bezel .
4. Remove the two M2.5 x 4-mm screws that secure the display latch bracket to the top cover.
5. Lift the display bracket out of the top cover, and then remove the display latch.
Back to Contents Page
and pull-tab)
2 top display-cable connector
3 pull-tab on bottom flex-cable
connector
NOTICE: Disconnect the computer and any attached devices from electrical outlets, and remove any installed batteries.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by touching an unpainted metal surface on the computer.
1 top cover 8M669
2 M2.5 x 4-mm screws (2) 6240E
3 display latch bracket
