1-2 Dell Latitude LM Systems Service Manual
warm swapping. However, the CD-ROM must be in the computer before or
during boot in order for the drivers to load.
• Built-in serial infrared transmitter/receiver, effective to 1 m (3.3 ft).
• Support for connecting an external diskette drive to the parallel connector
on the I/O panel.
P
hysical Description
Figure 1-1. Front View of the Portable Computer
Figure 1-2. Back View of the Portable Computer
LCD assembly
keyboard
options bay
touch pad
latch (2)
power button
hard-disk
drive bay
main-battery
compartment
microphone
status display
panel
power/suspend
indicator
touch pad
button (2)
display close
button
PS/2 connector
PC Card slots
parallel port connector
serial port connector
I/O panel
service tag number AC adapter
connector
expansion connector
infrared port
monitor connector
external
microphone connector
headphones/speakers
connector
