Dell Inspiron 9200 - Manual (Page 76)

76
Adding and Replacing Parts
www
.dell.com | support.dell.com
3 Turn the computer over, loosen the captive screws on the memory module cover, and then
remove the cover.
NOTICE:
To prevent damage to the memory module connector, do not use tools to spread the memory-
module securing clips.
4 If you are replacing a memory module, remove the existing module:
a Use your fingertips to carefully spread apart the securing clips on each end of the memory
module connector until the module pops up.
b Remove the module from the connector.
D5169bk1.book Page 76 Thursday, October 21, 2004 4:37 PM
