System Components
Dell™ X200 Service Manual
Back to Contents Page
NOTICE:
Only a certified service technician should perform repairs on your computer. Damage due to servicing that is not authorized by Dell is not
covered by your warranty.
NOTICE:
Unless otherwise noted, each procedure in this manual assumes that a part can be replaced by performing the removal procedure in reverse
order.
1 display
8
battery
2 keyboard
9
bottom case
3 keyboard tray
10 memory module cover
4 cooling fan
11 Mini PCI card cover
5 system board
12 reserve battery
6 modem daughter card 13 speakers (2)
7 hard drive
14 palm rest
