Coin-Cell Battery
Dell™ Latitude™ 120L Service Manual
Removing the Coin-Cell Battery
Replacing the Coin-Cell Battery
Removing the Coin-Cell Battery
1. Follow the instructions in Before Working Inside Your Computer .
2. Remove the hinge cover. See Removing the Hinge Cover .
3. Remove the keyboard. See Removing the Keyboard .
4. Disconnect the coin-cell battery cable from the system board connector.
5. Remove the cable from the routing guides and lift the coin-cell battery from the computer.
Replacing the Coin-Cell Battery
1. Connect the cable to the system board connector.
2. Route the cable through the channel and press the coin-cell battery into place.
CAUTION: Before performing the following procedures, follow the safety instructions in the Product Information Guide.
CAUTION: To prevent static damage to components inside your computer, discharge static electricity from your body before you touch any of
your computer's electronic components. You can do so by touching an unpainted metal surface.
