Fan
Dell™ Latitude™ 120L Service Manual
Removing the Cooling Fan
1.
Follow the instructions in
Before Working Inside Your Computer
.
2.
Remove the hard drive. See
Removing the Hard Drive
.
3.
Remove the optical drive. See
Removing the Optical Drive
.
4.
Remove the memory module. See
Removing a Memory Module
.
5.
Remove the Mini PCI card. See
Removing the Mini PCI Card
.
6.
Remove the processor thermal-cooling assembly. See
Removing the Processor Thermal-Cooling Assembly
.
7.
Remove the processor. See
Removing the Processor Module
.
8.
Remove the hinge cover. See
Removing the Hinge Cover
.
9.
Remove the keyboard. See
Removing the Keyboard
.
10.
Remove the display assembly. See
Removing the Display Assembly
.
11.
Remove the palm rest. See
Palm Rest
.
12.
Remove the modem. See
Removing the Modem
.
13.
Remove the speakers connector. See
Removing the Speakers
.
14.
Remove the system board. See
Removing the System Board
.
15.
Disconnect the fan power cable from the system board.
16.
Turn the system board over and remove the four M2.5 x 5-mm screws holding the metal plate in place.
CAUTION:
Before performing the following procedures, follow the safety instructions in the Product Information Guide.
CAUTION:
To prevent static damage to components inside your computer, discharge static electricity from your body before you touch any of
your computer's electronic components. You can do so by touching an unpainted metal surface.
