Memory, Optical Drive, and Mini PCI Card
Dell™ Latitude™ 120L Service Manual
Memory
Removing a Memory Module
1.
Follow the instructions in
Before Working Inside Your Computer
.
2.
Ground yourself by touching one of the metal connectors on the back of the computer.
3.
Turn the computer upside-down, loosen the captive screws on the memory module/Mini PCI cover, and then remove the cover.
4.
If you are replacing a memory module, remove the existing module:
a.
Use your fingertips to carefully spread apart the securing clips on each end of the memory module connector until the module pops up.
b.
Remove the module from the connector.
CAUTION:
Before working inside your Dell™ computer, follow the safety instructions in the
Product Information Guide.
CAUTION:
To prevent static damage to components inside your computer, discharge static electricity from your body before you touch any of
your computer's electronic components. You can do so by touching an unpainted metal surface.
NOTE:
Memory modules purchased from Dell are covered under your computer warranty.
NOTE:
If you leave the area, ground yourself again when you return to the computer.
1
captive screws (3)
NOTICE:
To prevent damage to the memory module connector, do not use tools to spread the memory-module securing clips.
