Removing and Installing Parts
93
8 Insert the Media Card Reader by sliding and holding the drive release latch downward. Then,
slide the drive in to seat it in the computer.
9 Route the USB cable through the cable routing clip.
10 Replace the computer cover (see page 99).
CD/DVD Drive
CAUTION:
Before you begin any of the procedures in this section, follow the safety instructions
located in the Product Information Guide.
CAUTION:
To guard against electrical shock, always unplug your computer from the electrical outlet
before removing the cover.
FlexBay
cable
Media Card Reader
