Mini PCI Card
If you ordered a Mini PCI card with your computer, the card is already installed.
1. Follow the procedures in " Before You Begin ."
2. Remove the keyboard .
3. If a Mini PCI card is not already installed, go to step 4 . If you are replacing a Mini PCI card, remove the existing card:
a. Disconnect the Mini PCI card from any attached cables.
b. Release the Mini PCI card by spreading the metal securing tabs until the card pops up slightly.
c. Lift the Mini PCI card out of its connector.
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the Product Information Guide.
1 Mini PCI card
2 antenna wires (2)
1 Mini PCI card
2 metal securing tabs (2)
NOTICE: The connectors are keyed to ensure correct insertion. If you feel resistance, check the connectors and realign the card.
