NOTE: The 90-W AC adapter is optional and may not ship with your computer.
Types 90 W and 65 W
Input voltage 90–264 VAC (both)
Input current (maximum) 1.7 A (both)
Input frequency 47–63 Hz (both)
Output current:
90 W 5.62 A (maximum at 4-second pulse); 4.62 A
(continuous)
65 W 4.34 A (maximum at 4-second pulse); 3.34 A
(continuous)
Output power 90 W or 65 W
Rated output voltage 19.5 VDC (both)
Dimensions:
Height 33.8–34.6 mm (1.34–1.36 inches) (90 W)
27.8–28.6 mm (1.10–1.12 inches) (65 W)
Width 60.9 mm (2.39 inches) (90 W)
57.9 mm (2.28 inches) (65 W)
Length 153.42 mm (6.04 inches) (90 W)
137.2 mm (5.40 inches) (65 W)
Weight (without cables) 0.46 kg (1.01 lb) (90 W)
0.36 kg (0.79 lb) (65 W)
Temperature range:
Operating 0° to 35°C (32° to 95°F) (both)
Storage –40° to 65°C (–40° to 149°F) (both)
Physical
Height 34.3 mm (1.4 inches)
Width 312.0 mm (12.5 inches)
Depth 262.2 mm (10.5 inches)
Weight:
With travel module 2.2 kg (4.85 lb) (6 cell)
2.1 kg (4.68 lb) (4 cell)
With CD drive 2.4 kg (5.29 lb) (6 cell)
Environmental
Temperature range:
Operating 0° to 35°C (32° to 95°F)
Storage –40° to 65°C (–40° to 149°F)
Relative humidity (maximum):
Operating 10% to 90% (noncondensing)
Storage 5% to 95% (noncondensing)
Maximum vibration (using a random-vibration
spectrum that simulates user environment):
Operating 0.66 GRMS
Storage 1.30 GRMS
Maximum shock (measured with hard drive in head-
parked position and a 2-ms half-sine pulse):
Operating 142 G, 70 in/s
Storage 163 G
Altitude (maximum):
Operating – 15.2 to 3048 m (–50 to 10,000 ft)
Storage – 15.2 to 10,668 m (–50 to 35,000 ft)
