Dell Latitude D610 - Manual (Page 76)

1. Follow the procedures in " Before You Begin ."
2. Turn the computer over and release the captive screw from the modem cover.
3. Place your finger under the cover at the indentation and lift the cover open.
4. If a modem is not already installed, go to step 5 . If you are replacing a modem, remove the existing modem:
a. Remove the screw that secures the modem to the system board, and set the screw aside.
b. Pull straight up on the attached pull-tab to lift the modem out of its connector on the system board, and disconnect the modem cable.
5. Connect the modem cable to the modem.
6. Align the modem with the screw hole and press the modem into the connector on the system board.
7. Install the screw to secure the modem to the system board.
8. Replace the cover.
1 captive screw
1 screw
2 modem
3 coin-cell battery
NOTICE: The connectors are keyed to ensure correct insertion. If you feel resistance, check the connectors and realign the card.
