DC power supply (per power supply):
Wattage 450 W
Voltage 100–240 VAC, 50–60 Hz
Heat dissipation 2275 BTU/hr maximum
Output hold up time 20 ms minimum
Maximum inrush current Under typical line conditions and over the entire
system ambient operating range, the inrush current
may reach 55 A at 10 ms or less or 25 A at 150 ms or
less.
System battery CR2032 3.0-V lithium coin cell
Physical
Height 44.7 cm (17.6 inches)
Width 21.8 cm (8.6 inches)
Depth 57.41 cm (22.6 inches)
Weight 30.4 kg (67 lb), maximum configuration
Environmental
Temperature:
Operating 10° to 35°C (50° to 95°F)
Storage –40° to 65°C (–40° to 149°F)
Relative humidity:
Operating 20% to 80% (noncondensing)
Storage 5% to 95% (noncondensing)
Maximum vibration:
Operating 0.25 G (half-sine wave) at a sweep of 3 to 200 MHz
for 15 minutes
Storage 0.5 G at 3 to 200 Hz for 15 minutes
Maximum shock:
Operating six consecutively executed shock pulses in the
positive and negative x, y, and z axes (one pulse on
each side of the system) of 36 G for up to 2.6 ms
Storage six consecutively executed shock pulses in the
positive and negative x, y, and z axes (one pulse on
each side of the system) of 71 G for up to 2 ms
Altitude:
Operating – 16 to 3048 m (–50 to 10,000 ft)
Storage – 16 to 10,668 m (–50 to 35,000 ft)
NOTE: For the full name of an abbreviation or acronym used in this table, see the " Glossary ."
