a.Short grain is preferred for papers over 135 g/m 2 .
Selecting an Output Location
The printer has two output locations: the output tray (face down) and the rear door (face up).
To use the output tray, ensure that the rear door is closed. To use the rear door, open it.
Printing to the Output Tray
Output bins available
The following table provides information on standard and optional output bin capability and connectivity.
(47 lb bond)
Dual-web paper - 176 g/m 2
(47 lb bond)
Polyester - 176 g/m 2
(47 lb bond)
Vinyl - 176 g/m 2
(47 lb bond)
Integrated Forms Pressure-sensitive area
(must enter the printer
first) - 135-140 g/m 2
(36-40 lb bond)
Paper base (long grain) - 75-135 g/m 2
(20-36 lb bond)
Envelopes 25% Cotton
Content Maximum
Weight- 24 lb Sulfite, wood-free or up
to 25% cotton bonds - 75-105 g/m 2
(20-28 lb)
NOTE: If paper coming out of the output tray has problems, such as excessive curl, try printing to the rear door.
NOTE: To avoid paper jams, do not open or close the rear door while the printer is printing.
Output Bin Name Capacity Maximum Weight &
Media Type Supported How Many Can Be
Installed on the Printer?
Rear output Tray 100 sheets of 75 g/m 2
paper
Plain paper 60-216 g/m 2 ,
Label, Envelopes,
Cardstock,
Transparencies.
N/A - One is standard on
the printer and located at
the rear side.
