CAUTION:

Do not attempt to clear any jams using tools or instruments. This may permanently damage the

printer.

1 Duplex module
2 Print media source
3 Duplex cover
4 Feeder cover
5 Inner rear cover
6 Bias Transfer Roll (BTR) cover
7 Fuser cover
8 Paper cover (not present when duplex module has been installed)

Removing Print Jams Near the Fuser Unit

NOTE:

To resolve the message displayed on the operator panel, you must clear all print media from the print media

path.

When Using the Optional Duplex Module

1. Open the duplex module.
