STK14D88
Document Number: 001-52037 Rev. ** Page 3 of 17
Absolute Maximum Ratings
Voltage on Input Relative to Ground.................–0.5V to 4.1V
Voltage on Input Relative to V
SS
...........–0.6V to (V
CC
+ 0.5V)
Voltage on DQ
0-7
or HSB ......................–0.5V to (V
CC
+ 0.5V)
Temperature under Bias ............................... –55
°C to 125°C
Storage Temperature .................................... –65
°C to 140°C
Power Dissipation ............................................................. 1W
DC Output Current (1 output at a time, 1s duration)..... 15mA
NF (SOP-32) PACKAGE THERMAL CHARACTERISTICS
θ
jc
5.4 C/W;
θ
ja
44.3 [0fpm], 37.9 [200fpm], 35.1 C/W [500fpm].
RF (SSOP-48) PACKAGE THERMAL CHARACTERISTICS
θ
jc
6.2 C/W;
θ
ja
51.1 [0fpm], 44.7 [200fpm], 41.8 C/W [500fpm].
Note: Stresses greater than those listed under “Absolute
Maximum Ratings” may cause permanent damage to the device.
This is a stress rating only, and functional operation of the device
at conditions above those indicated in the operational sections
of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect
reliability.
DC Characteristics
(V
CC
= 2.7V-3.6V)
Symbol Parameter [2]
Commercial Industrial
Unit Notes
Min Max Min Max
I
CC1
Average V
CC
Current 65
55
50 70
60
55 mA
mA
mA t
AVAV
= 25ns
t
AVAV
= 35ns
t
AVAV
= 45ns
Dependent on output loading and
cycle rate. Values obtained without
output loads.
I
CC2
Average V
CC
Current during
STORE
3 3 mA All Inputs Don’t Care, V
CC
= max
Average current for duration of
STORE cycle (t
STORE
)
I
CC3
Average V
CC
Current at t
AVAV
=
200ns
3V, 25°C, Typical
10 10 mA W
≥ (V
CC
– 0.2V)
All Others Cycling, CMOS Levels
Dependent on output loading and
cycle rate. Values obtained without
output loads.
I
CC4
Average V
CAP
Current during
AutoStore Cycle
3 3 mA All Inputs Don’t Care
Average current for duration of
STORE cycle (t
STORE
)
I
SB
V
CC
Standby Current
(Standby, Stable CMOS Input
Levels)
3 3 mA E
≥ (V
CC
– 0.2V)
All Others V
IN
≤ 0.2V or ≥ (V
CC
–
0.2V)
Standby current level after nonvol-
atile cycle complete
I
ILK
Input Leakage Current
±1 ±1 μA
V
CC
= max
V
IN
= V
SS
to V
CC
I
OLK
Off-State Output Leakage Current
±1 ±1 μA
V
CC
= max
V
IN
= V
SS
to V
CC
, E or G
≥ V
IH
V
IH
Input Logic “1” Voltage 2.0 V
CC
+ .5 2.0 V
CC
+ .5 V All Inputs
V
IL
Input Logic “0” Voltage V
SS
– .5 0.8 V
SS
– .5 0.8 V All Inputs
V
OH
Output Logic “1” Voltage 2.4 2.4 V I
OUT
= – 2mA
Note:
2. The HSB pin has I
OUT
=-10uA for V
OH
of 2.4V, this parameter is characterized but not tested
