16
Rack Installation Guide
Removing the System from the Rack
CAUTION:
Because of the size and weight of the system, never attempt to remove the system from the mounting
rails by yourself.
To remove the system from the rack, perform the following procedure:
1 Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
Figure 1-8. Removing the System from the Rack
1 Mounting rails (2) 2 Thumbscrews (2) 3 Release button (2)
1
2
3
