Rack Installation Guide
9
Figure 1-2. VersaRails Rack Kit Contents
Installation Tasks
Installing a rack kit involves performing the following tasks (described in detail in subsequent sections)
in their numbered order:
1 Removing the rack doors
2 Marking the rack
3 Installing the mounting rails in the rack
• RapidRails installation
• VersaRails installation
4 Installing the system in the rack
5 Replacing the rack doors
1 Mounting rails (2) 2 10-32 x 0.5-inch flange-head Phillips screws (8)
2
1
