16
Table 2L — Electrical Data — Upgrade 3 Evaporator Motor with Upgrade 2 Condenser Motor
LEGEND
Table 3 — Evaporator-Fan Performance
LEGEND NOTES:
1. Refer to Table 1 for evaporator fan motor and drive information.
2. Upgrade 1 Static Motor is required for boldface values.
3. Upgrade 2 Static Motor is required for shaded values.
UNIT
50AH
V-PH
(60 Hz)
VOLTAGE
RANGE
COMPRESSOR
FAN MOTORS
POWER SUPPLY Evaporator
(Upgrade 3)
Condenser
(Upgrade 2)
Min Max QTY RLA LRA Hp FLA Hp FLA
Min Ckt
Amps
MOCP
Amps
024 208/230-1 187 254 1 N/A N/A N/A N/A N/A N/A N/A N/A
036
208/230-1 187 254
1
N/A N/A N/A N/A N/A N/A N/A N/A
208/230-3 187 254 N/A N/A N/A N/A N/A N/A N/A N/A
460-3 414 508 N/A N/A N/A N/A N/A N/A N/A N/A
048
208/230-1 187 254
1
19.9 109.0 1 3.2 3 /
4
3.2 31.3 50
208/230-3 187 254 13.6 83.1 1 2.4 3 /
4
2.4 21.8 35
460-3 414 508 6.1 41.0 1 1.2 3 /
4
1.2 10.0 15
060
208/230-1 187 254
1
26.4 134.0 1 3.2 3 /
4
3.2 39.4 65
208/230-3 187 254 16.0 110.0 1 2.4 3 /
4
2.4 24.8 40
460-3 414 508 7.8 52.0 1 1.2 3 /
4
1.2 12.2 20
072*
208/230-1 187 254
2
N/A N/A N/A N/A N/A N/A N/A N/A
208/230-3 187 254 N/A N/A N/A N/A N/A N/A N/A N/A
460-3 414 508 N/A N/A N/A N/A N/A N/A N/A N/A
096*
208/230-1 187 254
2
N/A N/A N/A N/A N/A N/A N/A N/A
208/230-3 187 254 13.6 83.1 2 6.0 3 8.4 45.0 55
460-3 414 508 6.1 41.0 2 2.9 3 4.0 20.6 25
HACR — Heating, Air Conditioning, and Refrigeration
Hp
— Horsepower
FLA — Full Load Amps
LRA — Locked Rotor Amps
MOCP — Maximum Overcurrent Protection (HACR breaker)
RLA
— Rated Load Amps
*Unit has two compressors.
UNIT
SIZE
50AH
CFM
EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0 1.2
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
024
900 509 0.11 632 0.14 739 0.19 833 0.24 919 0.30 997 0.37
800 495 0.07 623 0.12 733 0.17 829 0.22 915 0.28 993 0.34
700 470 0.06 604 0.10 717 0.14 814 0.19 901 0.25 979 0.31
036
1350 550 0.17 651 0.23 744 0.29 831 0.36 912 0.43 — —
1200 526 0.14 635 0.19 734 0.25 825 0.31 908 0.38 986 0.45
1050 510 0.11 627 0.16 731 0.21 824 0.27 910 0.33 988 0.40
048
1800 607 0.29 685 0.36 760 0.43 832 0.50 902 0.58 — —
1600 566 0.22 652 0.28 734 0.35 813 0.42 888 0.49 960 0.56
1400 537 0.17 632 0.23 722 0.29 806 0.35 886 0.42 962 0.49
060
2250 640 0.44 715 0.52 786 0.61 — — — — — —
2000 588 0.32 670 0.40 747 0.48 819 0.56 889 0.64 — —
1750 552 0.24 642 0.31 725 0.38 803 0.46 878 0.53 950 0.61
072
2700 461 0.36 543 0.47 619 0.60 689 0.75 — — — —
2400 449 0.29 537 0.40 616 0.53 — — — — — —
2100 435 0.24 529 0.34 611 0.47 683 0.61 — — — —
096
3600 555 0.74 618 0.87 680 1.01 — — — — — —
3200 514 0.66 584 0.80 652 0.81 707 0.94 769 1.10 — —
2800 448 0.37 552 0.51 626 0.64 695 0.79 759 0.95 818 1.12
Bhp — Brake Horsepower
