Clarion compact disc - Manual (Page 15)

Note:
• CD-ROM discs cannot be played.
Loading and playing a CD
* When a CD is already inserted (When the DISC
indicator
lights), press the FUNC button
and select CD mode. Playback starts automatically.
1) Press the CD button . The operation panel
turns downward and the CD Insertion slot
appears.
Note:
• When the operation panel angle has been adjust-
ed with the SLOPE button
(excluding the case
when it has been adjusted to the maximum
angle), a CD cannot be inserted because the
panel may damage it. Press the CD button
or
press and hold the SLOPE button to set the
panel to the maximum angle and insert the CD.
2) Insert the disc into the CD Insertion slot
with the label side facing up.
CD mode is set and playback begins auto-
matically.
* After a CD is inserted, the operation panel
closes automatically. Adjust the panel angle
with the SLOPE button
. When an operation
panel angle has been stored, it is set to that
position automatically.
* If the operation panel is turned downward after
ejecting a cassette tape or due to other opera-
tion, an alarm sounds, the operation panel
closes, and the CD playback begins automati-
cally.
Do not put your hand or fingers into the
Cassette Insertion slot or CD Insertion slot,
as this may cause a breakdown.
Be careful not to let your fingers get caught
in the panel when it turns upward or down-
ward.
3) Slide the Up/Down button to (right) or
(left) to select a track.
: Selects the next track. (Example: The
third track from the current one is select-
ed by sliding the button 3 times.)
To return to the beginning of the current
track, slide the Up/Down button
once
to (left).
: Selects the previous track. (Example:
The third track before the current one is
selected by sliding the button 1+3=4
times (the first sliding returns you to the
beginning of the current track).)
Ejecting the CD
1) Press the CD button to eject the CD.
2) Remove the CD.
Remove the CD only when the operation
panel is turned downward. The panel closes
automatically after a few seconds.
* When the operation panel angle has been
stored, it is set to that position.
Notes:
• Do not leave a disc in the ejected position. If the
unit is operated in such a condition, it may break
down or damage the disc.
• When inserting a disc, insert it until it is fully drawn
into the slot.
• When the operation panel is left in downward
position, a repeated beep sounds. Remove or fully
insert the CD or a tape and close the operation
panel.
• Be careful not to let your fingers get caught in the
panel when it turns upward or downward.
• When the CD button is pressed, the eject oper-
ation is performed even if a disc has not been
loaded. During the eject operation, the SLOPE
button
and the TAPE button cannot be
operated.
• If the operation panel is moved due to shock when
set to the maximum angle, it must be reset to the
maximum angle with the SLOPE button
before
the CD can be ejected by pressing the CD button
. 3
2
1 2
3
3
11
11
2
31
For 5-inch (12 cm) CD For 3-inch (8 cm) single CD
2
3
2
31
3
12 8
21
English
Owner
’s Guide
CD Mode Operations
CAUTION
