1-4 I n s t a l l i n g a R O M B C a r d
www
.dell.com | support.dell.com
F i g u r e 1 - 3 . S C S I B a c k p l a n e B o a r d
Installing the SCSI Backplane Board
1 Insert the SCSI backplane board into the chassis:
a Fit the metal tabs (one tab at each end of the backplane) into the slots in the
chassis wall and lower the backplane into the chassis, ensuring that the CD and
diskette drive interface cables are not caught under the backplane.
b Press down firmly over the handle to seat the backplane in its connector.
2 Pivot the release latch out into the securing slot in the chassis.
3 Connect the CD drive interface cable to the CD_ROM connector on the backplane
board. See Figure 1-3.
CD drive interface
connector (CD_ROM)
diskette drive interface connector
(FLOPPY)
handle
release latch
tabs (2)
