66 Copyright © Acronis, Inc., 2000-2010
2. Start the Bootable Media Builder either by selecting Tools > Create Bootable Media or, as a
separate component.
3. Select Bootable media type: Windows PE.
When creating a new PE ISO:

Select Create Windows PE 2.x or 3.0 automatically

The software runs the appropriate script and proceeds to the next window.
When adding the plug-in to the existing PE ISO:

Select Use WinPE files located in the folder I specify

Specify the path to the folder where the WinPE files are located.
4. [optional] Specify Windows drivers to be added to Windows PE. Once you boot a machine into
Windows PE, the drivers can help you access the device where the backup archive is located.
Click Add and specify the path to the necessary *.inf file for a corresponding SCSI, RAID, SATA
controller, network adapter, tape drive or other device. You will have to repeat this procedure
for each driver you want to be included in the resulting WinPE boot media.
5. Choose whether you want to create an ISO or WIM image or upload the media on Acronis PXE
Server.
6. Specify the full path to the resulting image file including the file name, or specify the PXE server
and provide the user name and password to access it.
7. Check your settings in the summary screen and click Proceed.
8. Burn the .ISO to CD or DVD using a third-party tool or copy to a flash drive.
Once the machine boots into WinPE, Acronis Disk Director starts automatically.
To create a PE image (ISO file) from the resulting WIM file:

replace the default boot.wim file in your Windows PE folder with the newly created WIM file. For
the above example, type:
copy c:\AcronisMedia.wim c:\winpe_x86\ISO\sources\boot.wim

use the Oscdimg tool. For the above example, type:
oscdimg -n –bc:\winpe_x86\etfsboot.com c:\winpe_x86\ISO
c:\winpe_x86\winpe_x86.iso
For more information on customizing Windows PE, see the Windows Preinstallation Environment
User’s Guide (Winpe.chm).
8.1.2 Working under bootable media
Operations on a machine booted with bootable media are almost the same as operations in the
running operating system. The difference is as follows:
1. The Check volume (p. 47) and Defragment volume (p. 48) operations are not available under
bootable media.
2. Specify the disk layout (p. 24), if two or more Windows operating systems installed on the
machine. If only one Windows operating system is installed, the disk layout of this operating
system will be used. For bare metal, or if no Windows operating system is found, the disk layout
will be used according to the bootable media environment (Linux-based or Windows PE).
3. The Linux-based bootable media shows local disks and volumes as unmounted (sda1, sda2...).
4. The log lifetime is limited to the current session. You can save the entire log or the filtered log
entries to a file.
