3) Two window thresholds shall be set at 40mm (A) and at 60mm (B) -> (characteristic 3).
Setting the window function:
Switching- / Teach function: 1
Point A absolute in tenth of mm: 400  0190 hex (= Switching point A)
Point B absolute in tenth of mm: 600  0258 hex (= Switching point B)
Parameter to be written:
Switching points work:
01900258 hex
5.2.3.2 Example Teach-in on object
The switching points are taught against an object.
Figure 5: Teaching the switching points
In order to obtain an inverted switching (characteristic 4) the distance from the sensor to Switching point A
must be bigger than the one to Switching point B.
Assigning of parameter
Switching-/Teach function
to a switching point or a
window threshold
Position the object at the
switching point.
Switching point Window threshold
Position the object at the
switch-on point.
Teach switching point in interim
register using command
Teach-in switching point A.
Position the object at the switch-
off point.
Teach switching point in interim
register using command
Teach-in switching point A or
Teach-in switching point B.
Interim register switching
points interim enables
reading and verification of
taught values at all times.
Teach switching point in interim
register using command
Teach-in switching point B.
Transfer switching points from
interim register to work register
using command Transfer
switching points and switch
to active.
Transfer switching points from
interim register to work register
using command Transfer
switching points and switch to
active. After value export to work
register, the interim register will
be restored to FFFF FFFF hex.
