Error correction and tips

6.1 Error correction

Error

Error correction

Linearity of the output does not
meet the expectations

Change the geometry and material of the target to match as closely as
possible to the standard target. If this is not possible, ask Baumer for a
customized version.

Slope is not steep enough

Use larger target or ask Baumer for a customized version.

The digital output is switching
differently if an object is
approaching or leaving.

This is due to the hysteresis of the sensor in order to guarantee stable
behavior.

Change History

2014-11-10

simg

Manual released in version 1.0
