N 155
www.baumer.com 15
4.5.2. N 155 reset to default „Q“ (51h)
This command is for resetting several parameters to default, either by individual or collective reset.
Data = q (71h) = reset parameters to default
Data = t (74h) = reset device identifier to 98.
Data = x (78h) = reset current value (lower line of display) to 0
Data = ∆ (7Fh) = all above functions except „r“ (72h) are accomplished.
Note: No profile reset. Profile reset by command „R“.
Example 1: Reset N 155 to default
SOH Adr Cmd Data EOT CRC
Send
01h 20h 51h 7Fh 04h AEh
SOH Adr Data EOT CRC
Response
01h 20h 6Fh 04h 52h N 155 replies by standard response ‚o’ (6Fh) = OK
Example 2: Reset all N 155 to default by broadcast command (Adr=99)
SOH Adr Cmd Data EOT CRC
Send
01h 83h 51h 7Fh 04h B3
Response no confirmation
4.5.3. Profile reset of the target display „K“ (4Bh)
This command is clearing all prior profiles.
Example 1: Profile reset in a specific N 155
SOH Adr Cmd Data EOT CRC
Send
01h 20h 4Bh 7Fh 04h C6h
SOH Adr Data EOT CRC
Response
01h 20h 6Fh 04h 52h N 155 standard reply ‚o’ (6Fh) = OK
Example 2: Profile reset with all N 155 by broadcast command (Adr=99)
SOH Adr Cmd Data EOT CRC
Send
01h 83h 4Bh 7Fh 04h DBh
Response No confirmation
Important: After profile reset all profile data are set to auf FFFFFFhex respectively FFhex (current profile
number). The display will show 5 dashes instead of the target.
