Operating Instructions SWTD-1000 DYNALCO
1 //
1. Safety Instructions
SWTD-1000 may only be connected by trained & competent personnel.
Before opening the SWTD-1000 (Hardware configuration) the unit must be disconnected
from circuits that may exhibit dangerous potentials.
The instructions in this operating guide must be strictly adhered to. Not doing so may cause harm to
personnel, equipment or plant.
Instruments in a doubtful condition after electrical, climatic or mechanical overload must be immediately
disconnected and returned to the manufacturer for repair.
2. Product Features
The SWTD-1000 measures and monitor frequencies (speed proportional values) in the range
0 to 35,000 Hz.
The following are available:
• 1 Current output
• 1 Sensor frequency output
• 1 Relay
• 2 Limits
• 2 Parameter sets – selectable via binary input
• Sensor monitoring
• System monitoring
This product is configured via SWTD-1000 PC configuration software.
All settings are in revolutions per minute (RPM).
