6.2 Terminals
SWTD-1000
Sh
0VS
Ana.
+Vout
Dig.
+Bin +PO -PO
NC
NO Com +AO -AO
Gnd +24V
Sensor connections
SH
: Screen – Sensor cable
0VS
: Sensor Reference voltage
+VOut : Sensor Supply
Ana.
: Sensor signal analog
Dig.
: Sensor signal digital
Open Collector output
+PO
: Open Collector Output
-PO
: Signal reference for the Open
Collector
Relay output
NC :
Normally
closed
NO :
Normally
open
Com :
Common
Analog output
+AO
: current positive
- AO
: current negative
Supply
+24V : Power (10 ... 36 V)
Gnd
: Power reference
:
Earth
