Series 7 Digital Force Gauges
User’s Guide
38
Keys
Enabled
Alerts
Enabled
Set Points
Momentary
Automatic Shutoff
Enabled
Set Minutes
5
Backlight Auto
Set Minutes
1
Initial Settings
Units
lbF
Mode
Real Time
Passwords All
disabled
18.3 Capacity x Resolution
Model lbF ozF kgF gF
N
kN mN
M7-012
0.12 x 0.00002
2 x 0.0005
-
50 x 0.01
0.5 x 0.0001
-
500 x 0.1
M7-025
0.25 x 0.00005
4 x 0.001
-
100 x 0.02
1 x 0.0002
-
1000 x 0.2
M7-05
0.5 x 0.0001
8 x 0.002
-
250 x 0.05
2.5 x 0.0005
-
2500 x 0.5
M7-2
2 x 0.0005
32 x 0.01
1 x 0.0002
1000 x 0.2
10 x 0.002
-
-
M7-5
5 x 0.001
80 x 0.02
2.5 x 0.0005
2500 x 0.5
25 x 0.005
-
-
M7-10
10 x 0.002
160 x 0.05
5 x 0.001
5000 x 1
50 x 0.01
-
-
M7-20
20 x 0.005
320 x 0.1
10 x 0.002
10000 x 2
100 x 0.02
-
-
M7-50
50 x 0.01
800 x 0.2
25 x 0.005
25000 x 5
250 x 0.05
-
-
M7-100
100 x 0.02
1600 x 0.5
50 x 0.01
50000 x 10
500 x 0.1
-
-
M7-200
200 x 0.05
3200 x 1
100 x 0.02
-
1000 x 0.2
1 x 0.0002
-
M7-500
500 x 0.1
8000 x 2
250 x 0.05
-
2500 x 0.5
2.5 x 0.0005
-
COF and user-defined units are excluded from the above chart.
18.4 Load Cell Deflection
Model Deflection
(in
[mm])
M7-012
0.005 [0.13]
M7-025 – M7-500
0.010 [0.25]
