Select “+ More” for additional options:
9.6.3 Stop Condition
Data capture is automatically terminated when the Stop Condition has been reached. Several conditions
are available, as shown below:
When data capture has stopped, the data may be automatically transmitted in bulk to a PC program such
as MESUR
TM
gauge (see the following sub-section for details). Data may also be transmitted manually
through the Memory section.
Note 1: If the Stop Condition does not occur, data capture stops automatically when the memory
is full.
Function
Data capture is initiated when:
Momentary HiLo
An external trigger occurs.
See External Trigger sub-section for details for each of these functions.
Momentary LoHi
Maintained High
Maintained Low
Start Force
The desired trigger force is reached. Toggle between compression and tension
directions by pressing the DIRECTION key.
DATA Key
The DATA key is manually pressed.
Function
Data capture terminates when:
Samples
The desired number of samples (data points) has been captured.
Stop Force
The desired force has been reached.
Memory Full
5,000 data points have been captured.
DATA Key
The DATA key is manually pressed.
START CONDITION 2
Start Force
3.500 lbF
* DATA Key
STOP CONDITION
*
Samples:
10
Stop Force
2.500 lbF
Memory Full
DATA Key
START CONDITION
Momentary HiLo
Momentary LoHi
* Maintained High
Maintained Low
+ More
