Series 7 Digital Force Gauges

User’s Guide


29

The gauge can be calibrated at up to 10 points in each direction. Enter the number of calibration
points for each direction (compression and tension). At least one point must be selected for each
direction.

Note: To achieve the accuracy specification of ±0.1%, it is recommended to calibrate the gauge
at 5 or more even increments in both tension and compression directions. For example, a gauge
with capacity of 10 lbF should be calibrated at 2, 4, 6, 8, and 10 lb loads in each direction.

3. To escape the Calibration menu at any time, press ESCAPE. The display appears as follows:

Selecting “Cancel” will revert back to the Calibration setup. Selecting “Exit w/o saving” will return
to the menu without saving changes.

4. After the number of calibration points has been entered, press ENTER. The display appears as

follows:

5. Place the force gauge horizontally on a level surface free from vibration, then press ZERO. The

gauge will calculate internal offsets, and the display appears as follows:

CALIBRATION

NOT COMPLETE


Cancel

Exit w/o saving

CALIBRATION

Enter # cal points

(1 to 10)

Compression:

5

Tension:

5

CALIBRATION

OFFSET


Please wait…

CALIBRATION

OFFSET

Place force gauge
horizontally, then
press ZERO.
