Series 7 Digital Force Gauges
User’s Guide
28
ETLH
Enable reading captured on a low to high transition
ETD
Disable External trigger mode
Input / Output Bits
Sn
Set output bit (open drain, pull to ground). n=0, 1, 2
Cn
Clear output bit. n=0, 1, 2
Rn
Read current status of output bit or level of input pin. n=0, 1, 2 ,3
Personality
RN
Read product name
RM
Read
model
number
RV
Read firmware version number
RS
Read serial number
Other Commands
AOFFn
Auto-shutoff. n=0-30 minutes. 0=auto shutoff disabled
SAVE
Save current settings in nonvolatile memory
LIST
List current settings and status
Following is an example LIST output:
V1.00;LBF;CUR;FLTC8;FLTP1;AOUT00;AOFF5;FULL;IPOL0;OPOL0;MIT;POL;B0
All fields are separated by “;”. The first field shows the firmware version, the last field shows the remaining
battery power (B0=full charge, B3=minimum power). All other fields show the status of settings and
features using the same abbreviations as the commands to set them.
Any detected errors are reported back by means of the following error codes:
*10
Illegal
command
*11
Not
applicable
*21
Invalid
specifier
*22 Value too large
15 CALIBRATION
15.1 Initial Physical Setup
The gauge should be mounted vertically to a test stand or fixture rugged enough to withstand a load
equal to the full capacity of the instrument. Certified deadweights or master load cells should be used,
along with appropriate mounting brackets and fixtures. Caution should be taken while handling such
equipment.
15.2 Calibration Procedure
1. Select
Calibration from the menu. The display appears as follows:
2. Press
DIRECTION to invert the display, if desired. ENTER to continue. The display appears as
follows:
CALIBRATION
To invert the
display, press the
DIRECTION button,
then press ENTER.
