11.5 Information / Welcome Screen
The following screen is displayed at power up and can be accessed at any time by selecting Information
from the menu:
12 SPECIFICATIONS
12.1 General
Accuracy: ±0.2% of full scale ±1 digit
Sampling rate: 3,000 Hz
Power: AC or rechargeable battery. Low battery indicator appears when battery level is low, and
gauge powers off automatically when power reaches critical stage.
Battery life: Backlight on: up to 7 hours of continuous use
Backlight off: up to 24 hours of continuous use
Measurement units: lbF, ozF, gF, kgF, N, kN, mN (depending on model)
Outputs: USB / RS-232: Fully configurable up to 115,200 baud.
Mitutoyo (Digimatic): Serial BCD suitable for all Mitutoyo SPC-compatible devices.
Analog: ±1 VCD, ±0.25% of full scale at capacity,
General purpose: Three open drain outputs, one input.
Set points: Three open drain lines.
Configurable settings: Digital filters, outputs, automatic shutoff, default settings, key tones, audio alarms,
calibration
Safe overload: 150% of full scale (display shows “OVER” at 110% and above)
Weight (gauge only): M4-012 – M4-100: 1.0 lb [0.45 kg]
M4-200 – M4-500: 1.2 lb [0.54 kg]
Included accessories: Carrying case, chisel, cone, V-groove, hook, flat, extension rod, AC adapter, battery,
USB cable, resource CD (USB driver, MESUR Lite software, MESURgauge DEMO
software, and user’s guide), NIST-traceable certificate of calibration with data
Warranty: 3 years (see individual statement for further details)
12.2 Factory Settings
Parameter Setting
Set points
Upper
Lower Disabled (defaults to 80% of full scale when enabled)
Disabled (defaults to 40% of full scale when enabled)
Filters
Current
Displayed 1
1024
DATA Key
RS-232/USB
Mitutoyo
Memory Storage Enabled
Disabled
Enabled
Serial/USB
RS-232 Selected
USB Selected
Baud Rate
Data Format Enabled
Disabled
9,600
Numeric + units
Mitutoyo BCD Disabled
