10
Harmonics:
Displaying of the variables
Pass 999
12
7 12
To begin with
Generated
Imported
90
°
270
°
0
°
180
°
5
This angle is displayed only if the measurements
are taken in a three-phase system with neutral.
❑
Pages relating to the energy meters
❑
Page "25" (12 in single phase mode)
Displaying of the total energy meters
key disabled.
❑
Page "26" (13 in single phase mode)
Displaying of partial energies
key is active; modification of tariff/displayed period.
By pressing the key for the first time, the range
relating to the season is highlighted. By using the and
keys, it's possible to change the season displayed in
that page. Pressing the key another time, the range
relating to the period is highlighted. Using the and
keys, it's possible to change the tariff period within the
displayed season. Pressing the key for the third time,
you go back to the measuring page. The changes of
season and tariff period only refer to the displaying of the
values stored in the corresponding season and period.
The changes carried out in this page do not have
any influence on the method of tariff management
of the instrument; they are only valid for display
purposes.
