MIN/MAX VALUES

This function allows the user to as-
sociate some variables to the auto-
matic recording of maximum values
(from MAX1 to MAX12) and mini-
mum values (from MIN1 to MIN8).
To use this function, proceed as fol-
lows: select the MIN MAX VALUES

function using the

and

keys

and confirm it with

A new window will appear showing
you the list of available memory lo-
cations: select the locations using
the

and

keys, starting from

MAX1 for the maximum values and
MIN1 for the minimum values. Press

to open the secondary menu

with the list of the available variables
to be selected.

Press

; select the variable to be

displayed by means of the

and

keys and confirm it with

To reset your choices and go back

to the main menu press
