Section 3
Connecting to Other Liquid
Chromatography Systems
Bio-Scale Mini cartridges can be connected to any liquid
chromotography system, provieded that the maximum
pressure limits for the 10 ml (3 bar, 45 psi, or 300 kPa) or
for the 50 ml (2.6 bar, 40 psi, or 260 kPa) cartridges are
not exceeded. It is recommended that the system
pressure limit be set according to the cartridge pressure
limit. Pressures in excess of 3 bar are usually caused by
restrictions in tubing or detector cells downstream from
the cartridge. Bio-Rad offers two fittings kits for easy
connection of a Bio-Scale Mini cartridge to a BioLogic
DuoFlow, HPLC, or FPLC-type system.
3.1 Connecting to a BioLogic DuoFlow
System
The luer to BioLogic system fittings kit (catalog
#732-0113) includes 1/4-28 female to male luer
and 1/4-28 female to female luer to connect one
Bio-Scale Mini cartridge to the BioLogic DuoFlow
system, see Figure 4.
