3. Connect the inlet of the cartridge to the male
luer fitting on the MV-6 sample inject valve (see
Figure 2). If not using the MV-6 sample inject
valve, connect a barb to male luer fitting on the
1.6 mm ID tubing, then connect to the top of the
female luer on the Bio-Scale Mini cartridge. For
optimum performance, a cartridge should be
mounted vertically with the arrow on the
cartridge pointing downward (see Figure 3).
4. Connect the cartridge outlet to the 1.6 mm ID
tubing leading to the BioLogic LP system optics
module or to the Model EM-1 Econo
™ UV
monitor. It is recommended to use the shortest
length (approximately 10 cm) of 1.6 mm ID
tubing. Connect a barb to female luer to the
1.6 mm ID tubing, then connect to the bottom
of the male luer on the Bio-Scale Mini
cartridge.
7
