1.2 Features
The PowerPac HV has the following features:
• Constant voltage, voltage ramping, constant current or constant power operation with
automatic crossover and temperature control mode
• Backlit LCD screen
• Continuous display of all parameters
• Continuous, timed and Volthours run control
• Nine (9) programmed runs, each containing up to nine steps
• Pause mode for editing running parameters
• Automatic detection of no-load, short circuit, rapid resistance change, ground leak, fan
failure and system overheating
• Automatic completion (if desired) of a run interrupted by AC power failure
• Stackable case with adjustable viewing angle (Figure 3)
• Adjustable LCD display contrast
• EN 61010 international safety certification
• Input power 100–120/220–240 VAC, 50/60 Hz, auto-switching
• Four output terminals
Fig. 3. Front panel with legs.
LEGS
(LOWERED POSITION)
1 2 abc 3 def
4 ghi 5 jkl 6 mno
7 pqrs 8 tuv 9 wxyz
EDIT 0 CE
