CONTROL CABINET PARTS LIST
Ordering Information
The Letters “XXX” Define the
Type of Gas:
Oxygen
= OXY
Nitrogen = NIT
Medical Air = AIR
Carbon Dioxide = CO2
Nitrous Oxide
= N2O
M2-HBYY-XXL-XXX
The Letters “XX” Define the Number
of Cylinders:
2 x 2 use 04
4 x 4 use 08
The Letters “YY” Define the Type of
Header-Bar Assembly:
“TS”
= Straight c/w Stainless Pigtails
“TC” = Straight c/w Copper Pigtails
“XS” = Staggered c/w Stainless Pigtails
“XC” = Staggered c/w Copper Pigtails
Manifold Cabinet:
Header-Bar Assembly:
Wall Bracket for Header-bar Assembly: M-X-HB-WLBRKIT
DL = Dome Loaded (NFPA)
The Letter “L” Defines
the Language
U = English (NFPA)
S = Spanish
HH = High Pressure
HHH = Heaters
A = Analog
M3A-DL-HH-L-XXX
DESCRIPTION MODEL NUMBER
Pressure transducer for Oxy, N₂O, Air, CO₂, & Nit
Line pressure regulator for Heavy Duty Manifolds (Left)
Line pressure regulator for Heavy Duty Manifolds (Right)
Line pressure regulator for Heavy Duty Manifolds (For NIT, Left)
Line pressure regulator for Heavy Duty Manifolds (For NIT, Right)
Operating pressure regulator for HD Manifolds (Left)
Operating pressure regulator for HD Manifolds (Right)
Repair Kit Line pressure regulator - HD
Repair Kit Operating pressure regulator
M2-X-MAN-07B
M2-X-MAN-42E-L
M2-X-MAN-42E-R
M2-X-MAN-42E-LN
M2-X-MAN-42E-RN
M3-X-MAN-18DL-L
M3-X-MAN-18DL-R
M2-REG700-RK
M2-REG250-RK-HP
