Appendix
Great Plains Manufacturing, Inc.
13
2013-08-27
116-284M
Appendix
Part Lists
New Parts
The part call-out numbers in this list match all Figures in
these installation instructions. Part descriptions match
those in your updated Parts Manual.
Quantities are units (“ea”).
Kit Contents
Existing Parts
Callout
Number
Quantity in Kit
Part
Number
Part
Description
11
1
1
116-284M
MANUAL LOUP SHAFT MONITOR
12
2
3
116-019D
SHAFT SENSOR MOUNT
13
2
3
116-020D
SMALL CUP SENSOR MOUNT
14
15
15
800-052C
HOSE CLIP 5/8 I.D.
15
20
20
800-112C
CABLE TIE .19X7.25 1.75D 50LB
16
6
9
801-199C
SCR SELF TAP #10 X 3/4
17
15
15
802-257C
HFSS 1/4-20X3/4 GR5
18
1
-
823-402C
LOUP 2 CHANNEL SHAFT MONITOR
19
-
1
823-403C
LOUP 3 CHANNEL SHAFT MONITOR
20
-
1
833-595C
SHAFT MONITOR EXT. 30’6P WP
21
1
-
833-596C
SHAFT MONITOR EXT. 25’4P WP
22
-
1
253016
LOUP 2 CHANNEL SHAFT MONITOR
23
1
-
253017
LOUP 3 CHANNEL SHAFT MONITOR
24
2
3
253100
LOUP SHAFT SENSOR 2&3 CHANNEL
25
1
-
318917
HARNESS 2 SHAFT MONITOR LOUP
26
-
1
318951
HARNESS 3 SHAFT MONITOR LOUP
27
2
3
540017
MAGNET, ADHESIVE BACKED, LARGE
28
4
6
710425
NUT HEX JAM, PLASTIC M16 X 2
29
4
6
770026
CABLE TIE
Callout
Number
Part
Number
Part
Description
Part
Disposition
51
SPACER TUBE
Modified
52
802-196C
HFSS 1/4-20X5/8 GR5
Removed. Not re-used.
53
803-088C
NUT HEX LOCK 1/4-20 FLG
Removed and re-used.
54
817-075C
SEED CUP ASSEMBLY
Left in place - for parts ID
55
817-094C
SEED CUP ASSEMBLY-1 1/4
Left in place - for parts ID
