SAFETY DECALS
--IMPORTANT--
* Your 3-Section Solid Stand Folding Drill comes equipped with all safety decals in place.
* Always keep safety decals clean and legible.
* Replace all damaged or missing safety decals. To order new safety decals go to your Great
Plains Dealer and reference part numbers as shown on pages 1-3 & 1-4.
* To install new safety decals:
A) Clean the area the decal is to be placed. (Refer to pages 1-3 & 1-4.)
B) Peel backing from decal and press firmly onto clean surface.
Reflector - Red
Reflector - Amber
Slow Moving Vehicle
THIS MACHINE IS EQUIPPED WITH REPHASING MASTER SLAVE
LIFT CYLINDERS. THESE CYLINDERS MAY AFTER A PERIOD OF
TIME GET OUT OF TIME OR PHASE. THE EFFECTS OF THIS CAN
BE SEEN WHEN ONE SECTION IS RUNNING TOO LOW OR TOO
HIGH BECAUSE ITS LIFT CYLINDER IS EITHER OVEREXTENDED
OR OVERRETRACTED COMPARED TO THE OTHER LIFT CYLIN-
DERS. TO REPHASE THE CYLINDERS, RAISE THE IMPLEMENT
COMPLETELY UP AND HOLD THE TRACTOR HYDRAULIC LEVER
ON FOR A FEW SECONDS TO GIVE THE CYLINDERS TIME TO
REPHASE. THIS SHOULD BE DONE EACH TIME THE MACHINE IS
RAISED OUT OF THE GROUND. MOMENTARILY REVERSING THE
HYDRAULIC LEVER IMMEDIATELY AFTER REPHASING TO ALLOW
THE CYLINDERS TO RETRACT ABOUT 1/2" WILL HELP IN MAIN-
TAINING A LEVEL IMPLEMENT.
LIFT CYLINDERS
OPERATING INSTRUCTIONS
818-043C
- - Read Owner’s Manual Before Operat-
ing Drill
- - Stand Clear When Folding And Un-
folding Drill
- - Stand Clear When Raising And Low-
ering Drill
- - Keep All Safety Shields And Devices
In Place
- - Keep Hands And Clothing Away From
Moving Chains And Sprockets
- - Never Ride On Drill
- - Before Transporting, Be Sure Trans-
port Lock Pins Are In Transport Posi-
tion And Folded Boxes Are Locked In
- - Hitch Drill To Tractor Before Folding,
Unfolding Or Filling With Seed
- - Always Lower Or Properly Support
Drill Before Servicing
- - Escaping Hydraulic Fluid Can Cause
Serious Injury.
818-078C
!
CAUTION
!
WARNING
20 MPH MAX.
TRANSPORT SPEED
EXCEEDING 20 MPH MAY RESULT IN LOSS OF VEHICLE
CONTROL AND / OR IMPLEMENT DAMAGE
818-188C
818-055C
SAFETY HAZARD
Negative tongue weight may cause
immediate elevation of tongue resulting
in damage or personal injury.
818-019C
WARNING ! !
USE EXTREME CAUTION
WHEN UNHITCHING IMPLEMENT
FROM TRACTOR.
WARNING
!
STAND CLEAR WHILE FOLDING,
UNFOLDING, RAISING, OR
LOWERING IMPLEMENT.
818-045C
818-229C
818-230C
