Great Plains Manufacturing, Inc. Appendix 19
12/28/2007 401-514M
401-516A Part Numbers
Existing Parts Affected
Callout Part Number Quantity Part Description
401-514M 1 MANUAL 82 & 150 BU AIR KIT (This manual. Not shown.)
403-234D 1 BULK HOPPER UNLOAD DOOR (new, with two stop bolt holes)
403-241H 1 LOWER AIR PIPE SUPPORT 82 YP
403-242S 1 UPPER PIPE SUPPORT WELDMENT
403-407D 1 BRACKET
403-408D 1 AIR TRANSFER TUBE CAP
802-004C 4 HHCS 1/4-20X3/4 GR5
802-080C 2 HHCS 7/16-14X1 GR5
803-006C 4 NUT HEX 1/4-20 PLT
803-015C 2 NUT HEX 7/16-14 PLT
804-006C 4 WASHER LOCK SPRING 1/4 PLT
804-014C 2 WASHER LOCK 7/16 PLT
804-041C 2 WASHER FLAT 7/16 SAE PLT
816-245C 1 RUBBER GUARD REAR CTR.OUTER
802-004C 1 HHCS 1/4-20X3/4 GR5
802-017C 2 HHCS 3/8-16X1 GR5
803-014C 2 NUT HEX 3/8-16 PLT
803-088C 2 NUT HEX LOCK 1/4-20 FLG
804-013C 2 WASHER LOCK SPRING 3/8 PLT
403-409D 2 BRACKET ANGLE WITH HOLES
403-427D 1 150 BU AIR PRESSURE PIPE
802-079C 4 HHCS 3/8-16X1 1/4 GR5
803-209C 4 NUT FLANGE LOCK 3/8-16 PLT
Callout Part Number Description Disposition
403-332D HOPPER STRAINER BASKET SUPPORT Removed, modified and re-installed.
403-234D
BULK HOPPER UNLOAD DOOR (single
stop bolt hole) Removed.
Not re-used.
802-004C HHCS 1/4-20X3/4 GR5 Removed and re-installed.
802-005C HHCS 1/4-20X1 GR5 Removed and re-installed.
802-167C HHCS 1/4-20X1 1/2 GR5 Removed and re-installed.
802-370C HHCS 1/4-20X1 3/4 GR5 Removed and re-installed.
803-088C NUT HEX LOCK 1/4-20 FLG Removed and re-installed.
803-230C NUT HEX FLANGE 1/4-20 PLT Removed and re-installed.
804-007C WASHER FLAT 1/4 SAE PLT Removed and re-installed.
11
12
13
13
15
16
17
18
19
20
21
22
23
24
17
27
28
29
30
31
32
33
34
81
82
83
84
85
86
87
88
89
