Refer to Figure 59
To adjust the frame, loosen the four hex nuts
on the
U-bolts and rotate the frame tube as necessary.
To adjust the tines, loosen the four
1 ⁄
2
inch hex nuts on
the
1 ⁄
2
inch U-bolts on the support bar . Rotate tine
tubes so the tines are against the stop bushings
and are angled back as necessary. Retighten hex nuts
on U-bolts.
Figure 59
Harrow Adjustment
16297
1
2
3
4
5
6
6
8
7
1
2
3
4 5
6 7 8
