Great Plains 2525P Operator Manual - Manual (Page 71)

4/23/2010 118-915M
69 Maintenance and Lubrication
Seed Flap Replacement (s/n 1466SS-)
Refer to Figure 98
To replace a seed flap use a needle nose or simi-
lar tool and squeeze the tabs together. Pull plastic
seed flap down out of metal bracket.
If replacing with 817-349C: Push new seed flap
up through metal bracket until tabs on seed flap
snap in place.
If replacing with 816-302C:
See seed flap replacement instructions below.
Seed Flap Replacement (s/n 1467SS+)
Refer to Figure 99
To replace an 816-302C seed flap use a needle
nose pliers or similar tool to grasp “T” top of flap.
Pull upward to pull flap up out of metal bracket
.
Push new seed flap down through metal brack-
et until flap snaps into place with “T” top resting
on top of bracket.
Figure 98
817-349C Seed Flap Replacement
18398
Squeeze tabs
together
Metal
bracket
1
2
1
Figure 99
816-302C Seed Flap Replacement
31047
2
1
2
