2525P and 2520P
118-915M 4/23/2010
38
Refer to Figure 52
4. Pull seed meter wheel out about 1/4 inch, or
past the wheel drive pin, and spin backward to
clean out seeds from top pockets.
5. Remove seed meter wheel.
NOTE: With the seed meter wheel removed,
you may want to check the meter for internal
damage or trash.
Refer to Figure 53
6. Place new wheel on meter wheel shaft and
push meter slide retaining clip forward while
pushing in seed meter wheel.
Refer to Figure 54
7. Be sure slots in the center of seed meter
wheel are aligned with the wheel drive pin on
the meter shaft.
Figure 52
Remove seed meter wheel
22861
Spin wheel
backward before
removing
Retaining
clip
Figure 53
Place new seed meter wheel on wheel shaft
22862
Wheel
drive pin
Figure 54
Position seed meter wheel
22863
