2525P and 2520P
118-915M 4/23/2010
62
Refer to Figure 82
6. Check for excess wear on meter slide (1).
Slight wear at the top corner is normal.
7. If slide is not excessively worn, stop here. If it
is, continue with the following steps to re-
place.
Refer to Figure 83
8. Remove retaining clip and pin from meter.
NOTE: Meter slide is spring loaded and the
two meter slide springs will be released when
you pull the pin. Use care not to lose pins and
springs.
9. Check removed pin for wear and replace if
worn.
Refer to Figure 84
10. Remove meter slide (1) with springs (2).
11. Place springs in new meter slide and install in
meter.
12. Reinstall seed meter wheel. Refer to page 37.
Figure 82
Meter slide location
18269
Figure 83
Meter slide retaining clip
22862
Retaining
clip
Figure 84
Meter slide 18269
