44 800 Table of Contents Index Great Plains Manufacturing, Inc.
175-057M Table of Contents Index 2011-10-25
Seed Cup Drive Shaft Sprocket
1 sliding sprocket
Type of Lubrication: Oil
Quantity: Coat thoroughly
Move the Seed Rate adjustment handle back and forth to
get oil into the square bore. Perform this with seed box
empty, or handle may be difficult to set to 100.
Clutch Shaft Input Chain
1 chain
Type of Lubrication: Chain Lube
Quantity: Coat thoroughly
Slack:
1 ⁄
2
inch (13 mm) in top span
Gearbox Input Chain
1 chain
Type of Lubrication: Chain Lube
Quantity: Coat thoroughly
Slack:
1 ⁄
2
inch (13 mm) in top span
50
12126
As Required
28291
As Required
28292
