4. T RANSPORT & P LACEMENT WHEATHEART - GHR & WHR GRAIN AUGERS
4.2. P LACEMENT P ROCEDURE GRAIN AUGERS SD
38 30662 R1
7. To raise auger check that the valve on hose to lift cylinders is open, raise the
auger to desired height, and close hose valve.
8. Move the auger into working position slowly. Do not unhitch and attempt to
move auger by hand.
9. Once auger is in position, chock wheels on both sides and apply the park
brake on the tractor (or chock its wheels as well) to prevent movement during
operation.
Important: When releasing auger from the towing vehicle, test the intake end for downward
weight. Do not raise the intake end above drawbar height. When the intake end
is elevated too high with auger in raised position, the balance of weight quickly
transfers to the discharge end, causing it to upend. Ensure proper anchoring /
support.
10. When operating auger in the raised position, rest the discharge end lightly on
the bin roof, or tie to bin to prevent wind from toppling auger. When operating
the auger in a freestanding position, anchor the intake end.
11. Anchor and/or support auger during operation.
• When lower half of auger empties of grain, the weight balance transfers
to upper end of auger, which can cause upending.
12. See “Completion / Clean Up” on page 42 for correct lowering procedure.
WARNING
If hose valve remains open, a loss of hydraulic
pressure within the tractor system will allow
the auger to lower inadvertently, damaging
equipment and/or causing personal injury.
Do not disconnect coupler under pressure.
Relieve pressure and then disconnect.
Fluid leaks in the hydraulic cylinders or hoses
will allow auger to lower inadvertently. Repair
all leaks and breaks immediately.
CAUTION
Do not use auger as a hoist to raise any object
regardless of weight. This will create an
unsafe condition and will void warranty.
